Portable Pack | Dosatron D3GL2 Green Line (Each)

DOSATRON is a solution for liquid to liquid precision dosing and mixing issues.

The DOSATRON water powered dosing pump is a simple and ingenious system that has demonstrated its worth since many decades in about a hundred countries.

Installed directly in the water supply line, the DOSATRON operates without electricity; it uses the flow of water as the power source. The water activates the DOSATRON, which takes up the required percentage of concentrate and injects it into the water. Inside the DOSATRON, the concentrate is mixed with the water, and the water pressure forces the solution downstream. Once adjusted, the dispenser requires no action or external control.

The dose of concentrate will be directly proportional to the volume of water entering the DOSATRON, regardless of variations in flow and pressure which may occur in the main line.

The high dosing precision eliminates all risks of overdosing, thus contributing to respecting the environment. For other fluids than water, please contact us.

FEATURES

• More efficient

• An optimised design

• Really adapted to the evolution of practices and treatments

• Highly ergonomic adjustment

SPECIFICATION

• Injection range 0,2 - 2 % [1:500 - 1:50]
• Water flow range 10 l/h - 3 m3/h
• Operating water pressure 0,3 – 6 bar
• Concentrated additive injection 0,02 l/h – 60 l/h
• Stroke volume ~ 0,53 l
• Connections NPT-BSP Ø 20x27 - 3/4"M
• Hose : PVC Ø 8x12 - Lg 1,75m

AVAILABLE OPTIONS

• (Integrated by-pass) system for manual activation of the additive suction (on) and stop (off)

• PVDF housing for highly concentrated acids and other aggressive concentrates

• Seals for highly concentrated acids (>15%) - PVDF systematic

• Automatic by-pass

MANOEUVRABILITY

The D3GL2 is mounted onto a trolley for easy maneuverability.
